Range

Type	Body diameter (mm)	Total diameter (body + CTN)	Length (mm)	Total weight (kg)	Body weight (kg)	CTN weight (kg)	Energy absorption (kNm)	Reaction force (kN)	Test pressure (kPa)	Hull pressure (kPa)	Safety valve pressure

NPF0510S	500	-	100	37	37	-	6	64	200	132
NPF0815S	800	-	1500	83	83	-	20	146	200	129
NPF0815C	800	1120	1500	249	83	166	20	146	200	129
NPF1015S	1000	-	1500	120	120	-	32	182	200	122
NPF1015C	1000	1320	1500	283	102	181	32	182	200	122
NPF1020S	1000	-	2000	146	146	-	45	257	200	132
NPF1020C	1000	1320	2000	321	128	193	45	257	200	132
NPF1220S	1200	-	2000	192	192	-	63	297	200	126
NPF1220C	1200	1520	2000	409	174	235	63	297	200	126
NPF1325S	1300	-	2500	258	258	-	102	427	200	130
NPF1325C	1300	1670	2500	621	253	368	102	427	200	130
NPF1525S	1500	-	2500	290	290	-	123	464	200	126
NPF1525C	1500	1820	2500	665	285	380	123	464	200	126
NPF1530S	1500	-	3000	332	332	-	153	579	200	132
NPF1530C	1500	1820	3000	728	330	398	153	579	200	132
NPF1730S	1700	-	3000	415	415	-	191	639	200	128
NPF1730C	1700	2100	3000	809	405	404	191	639	200	128
NPF2030S	2000	-	3000	534	534	-	264	750	200	133
NPF2030C	2000	2360	3000	1328	524	804	264	750	200	133
NPF2035S	2000	-	3500	594	594		308	875	200	128
NPF2035C	2000	2360	3500	1414	584	830	308	875	200	128
NPF2540S	2500	-	4000	1080	1080	-	663	1381	250	137	175
NPF2540C	2500	2900	4000	2266	1030	1236	663	1381	250	137	175
NPF2555S	2500	-	5500	1325	1325	-	943	2019	250	148	175
NPF2555C	2500	2900	5500	2840	1275	1565	943	2019	250	148	175
NPF3050S	3000	-	5000	1705	1705	-	1079	1903	250	135	175
NPF3050C	3000	3400	5000	3695	1625	1970	1079	1903	250	135	175
NPF3345S	3300	-	4500	1770	1770	-	1175	1884	250	130	175
NPF3345C	3300	3800	4500	3987	1690	2297	1175	1884	250	130	175
NPF3365S	3300	-	6500	2225	2225	-	1814	3015	250	146	175
NPF3365C	3300	3800	6500	5119	2145	2974	1814	3015	250	146	175
NPF4570S	4500	-	7000	3660	3660		3696	4470	250	151	175
NPF4570C	4500	5000	7000	8171	3580	4591	3696	4470	250	151	175
NPF4590S	4500	-	9000	4380	4380	-	4752	5747	250	146	175
NPF4590C	4500	5000	9000	10591	4300	6291	4752	5747	250	146	175
